How to perform a step of multiplication in the given fetch-execution cycle?

Asked By alber aqil 10 points N/A Posted on - 10/05/2011

This diagram describes the fetch-execution cycle. How can i perform another step for multiplication just after the step 4 and what value will be loaded in Program counter, AC and IR?

• Status: Open
• Question Views: 1458
• Answer Count: 2
• Vote Up 1 Vote Down

• Answer Accepted: Yes
• Question Category: Memory / RAM

Best Answer by Trixy Rasel

Go To Solution

Best Answer

Best Answer

Answered By Trixy Rasel 0 points N/A #87323

How to perform a step of multiplication in the given fetch-execution cycle?



Hi,

In fetch execution cycle it load one instruction register and the two data registers. And the PC points the next instruction to be fetched. After that the instruction will execute at next clock cycle.

Therefore the PC value does not change after step 4. Only the IR value will change. The value should be relevant to the multiplication.

About Trixy Rasel

Questions
1

Answers
37

Best Answers
4

• Vote Up 0 Vote Down

• Posted on - 09/05/2012
• Question Category: Memory / RAM

Answered By Shifflett Laurel 0 points N/A #197125

How to perform a step of multiplication in the given fetch-execution cycle?

Hellow Alber Aqil,

I am giving you important outline about fetch-execution cycle.

In Operand fetch step:

1.MAR <-PC

2.MDR <-MEM[MAR]

3.IR <-MDR

4.PC <-PC+1

5.DECODER <- IR.OP



In execution cycle:

1.MAR <-IR.ADDR

2.MDR <-MEM[MAR]

3.A <–A + MDR

4.DECODER <–0



Your multiplication operation can be performed By following the tables









I hope these will be effective



Shifflet Laurel





About Shifflett Laurel

Questions
2

Answers
154

Best Answers
78

• Vote Up 0 Vote Down

• Posted on - 01/18/2013
• Question Category: Memory / RAM
