In a Case diagram, what are the steps needed to supply and process goods and services. What steps are additionally needed to sophisticate another activity diagram, so that the process is confined?
Steps needed to supply and process goods and services in Case Diagram
The following are the steps that you will need to follow when you need to supply goods and services in a case diagram:
First, you will need to sources that you will use to gather the information.
Next, you will need to find the activities and the actions, which involve things that have to be done when people place a draw on the goods and services that you have offered.
You will thereafter need to adopt actors from business use cases, and in this case you will be trying to verify the individual that is responsible for whichever action.
The next thing that you will need to do is connecting the actions, and in this step you will be required to bring out the order in which the actions are to be processed.
Thereafter you will refine the activities, and here is whereby you will determine if there are any other activities that have to be added.
Lastly you will verify the view and determine if everything is correct.
